Pioneer VREC-Z810SH 1-Channel 4K Front Dash Cam, GPS, Wi-Fi, ADAS
Talk it through first
Send the model and year, with a photograph of the current screen if you have one, and we will confirm the exact specification, a fixed price and a fitting date. Most enquiries are answered the same day, and a message often reaches us faster than a call.
The Pioneer VREC-Z810SH is a single-channel 4K dash cam that records the road ahead at up to 3840 x 2160 through a Sony STARVIS sensor. It suits drivers who want maximum front detail plus driver aids: forward collision and lane departure warnings, voice guidance and voice commands. A hardwire kit is included for Parking Mode and 24/7 Security Mode.
Key features
- 4K (3840 x 2160) recording at up to 30fps, with 2K and Full HD options
- Sony STARVIS CMOS sensor with HDR and Night Time Mode
- 139° wide viewing angle, F1.8 lens
- Parking Mode and 24/7 Security Mode with built-in battery; hardwire kit included
- ADAS: Front Collision Warning, Lane Departure Warning and Stop and Go alerts
- Voice guidance and voice recognition for hands-free control
- Built-in GPS and Wi-Fi with the Pioneer Dash Camera Connect app
- 3-inch full colour LCD and camera swivel mechanism
- Optional ND-RC1 rear camera for two-channel recording
Specifications
- Channels: 1 (front only), rear camera optional (ND-RC1)
- Resolution: 4K 3840 x 2160, 2K 2848 x 1600 or Full HD 1920 x 1080
- Frame rate: 25 / 27.5 / 30fps
- Viewing angle: horizontal 115°, vertical 60°, diagonal 139°
- Sensor: Sony STARVIS, F1.8
- Screen: 3-inch full colour LCD
- Recording modes: normal, event, photo, parking (30 seconds before and after)
- Video format: MOV, H.265 (4K, 2K, Full HD) or H.264 (Full HD)
- ADAS: LDWS, FCWS, Stop and Go
- GPS and Wi-Fi: built-in
- Memory: microSDHC/SDXC class 10, 32GB to 256GB
- Power: 12V / 24V DC, hardwire power cable (3.3 m), approx. 4W front only, 6W with rear camera
- Operating temperature: -20°C to +60°C
- Dimensions: 93.7 x 63 x 49.3 mm, 152g
- Menu languages: English, French, German, Spanish, Polish, Russian
What's in the box
- Front camera
- Mounting bracket
- Hardwire power cable
- Quick start guide
- Warranty document
- Cleaning wipe
Frequently asked questions
Is a rear camera included with the VREC-Z810SH?
No. It is a 1-channel front camera. The ND-RC1 rear camera is sold separately and takes power draw from about 4W to 6W.
Does the VREC-Z810SH record while parked?
Yes. It has Parking Mode and 24/7 Security Mode, with a built-in battery. The hardwire kit needed for Security Mode is included in the box.
Is a memory card included?
A memory card is not listed in the box contents. The camera accepts class 10 microSD cards from 32GB to 256GB.
Fitting and installation
Fitting is not included. Installation prices vary, please enquire for more information if you require installation. 12K Retrofits can supply and fit this dash cam, with the wiring hidden and the camera hardwired for parking mode where supported.
Delivery
Delivered across the UK mainland by tracked courier. Delivery is included in the price shown.
